# A cheat sheet for custom TensorFlow layers and models

TensorFlow v2.5.0.

# Numpy mappings to TensorFlow

• Keep in mind for all operations: in TensorFlow, the first axis is the batch_size.
• Trick to get past the batch size when it’s inconvenient: wrap linear algebra in tf.map_fn , e.g. converting vectors of size n in a batch (batch_size x n) to diagonal matrices of size (batch_size x n x n) :
mats = tf.map_fn(lambda vec: tf.linalg.tensor_diag(vec), vecs)
• Sum an array: np.sum(x)tf.map.reduce_sum(x)
• Dot product of two vectors: np.dot(x,y)tf.tensordot(x,y,1)
• Matrix product with vector A.b : np.dot(A,b)tf.linalg.matvec(A,b)
• Trigonometry: np.sintf.math.sin
• Transpose (batch_size x n x m)(batch_size x m x n) : np.transpose(x, axes=(0,2,1))tf.transpose(x, perm=[0,2,1])
• Vector to diagonal matrix: np.diag(x)tf.linalg.tensor_diag(x)
• Concatenate matrices: np.concatenate((A,B),axes=0)tf.concat([A,B],1)
• Matrix flatten: [[A,B],[C,D]] into a single matrix:
tmp1 = tf.concat([A,B],2)
tmp2 = tf.concat([C,D],2)
mat = tf.concat([tmp1,tmp2],1)
• Kronecker product of a vector vec of size n (makes a matrix n x n): tf.tensordot(vec,vec,axes=0) except the vectors usually come in a batch vecs of size (batch_size x n) , so we need to map:
mats = tf.map_fn(lambda vec: tf.tensordot(vec,vec,axes=0),vecs)
• Zeros: np.zeros(n)tf.zeros_like(n) . Note that to avoid the error “Cannot convert a partially known TensorShape to a Tensor”, you should use tf.zeros_like instead of tf.zeros since the former does not require the size to be known until runtime, see also here.

# Part assignment by indexes

a = np.random.rand(3)
a[0] = 5.0
a = tf.Variable(initial_value=np.random.rand(3),dtype='float32')
a[0] = 5.0
# TypeError: 'ResourceVariable' object does not support item assignment
e = tf.one_hot(indices=0,depth=3,dtype='float32')# <tf.Tensor: shape=(3,), dtype=float32, numpy=array([1., 0., 0.], dtype=float32)>
a = a + (new_val - old_val) * e

# What do I need to implement to subclass a Layer?

• Obviously call super in the constructor.
• Obviously implement the call method.
• You should implement get_config and from_config — they are needed often for saving the layer, e.g. if save_traces=False in the model.
• @tf.keras.utils.register_keras_serializable(package="my_package") should be added at the top of the class. From the docs:
"my_model", custom_objects={"MyLayer": MyLayer}
)

# What do I need to implement to subclass a Model?

model.save("model", save_traces=False)# Or just save the weights
model.save_weights("model_weights")
@tf.keras.utils.register_keras_serializable(package="my_package")

# How to reduce the size of TensorBoard callbacks if you have a large custom model

logdir = os.path.join("logs",datetime.datetime.now().strftime("%Y%m%d-%H%M%S"))tensorboard_callback = tf.keras.callbacks.TensorBoard(logdir,
histogram_freq=1,
write_graph=False
)
val_checkpoint = tf.keras.callbacks.ModelCheckpoint(
'trained',
monitor='val_loss',
verbose=1,
save_best_only=True,
save_weights_only=True,
mode='auto',
save_frequency=1
)

# Conclusion

--

--

--
